In the refrigerating capacity of the evaporation temperature (KW),R404A/R507:-40℃:14.1; +5℃:19.2; R134a:-40℃:9.4; +5℃:13.6; R22/R407C:-40℃:15.8; +5℃:19.4; ODF(in):5/8; Maximum Discharge Volume:6.8m³/hr; Overall Dimensions(mm): D:102; A:25;H1:19;H2:306;H:382;F:/; Cubage(L):2.5L;

In the refrigerating capacity of the evaporation temperature (KW),R404A/R507:-40℃:5.3; +5℃:7; R134a:-40℃:3.6; +5℃:5.2; R22/R407C:-40℃:5.3; +5℃:7.0; ODF(in):1/2; Maximum Discharge Volume:2.6m³/hr; Overall Dimensions(mm): D:102; A:25;H1:19;H2:256;H:332;F:/; Cubage(L):2.2L;

In the refrigerating capacity of the evaporation temperature (KW),R404A/R507:-40℃:88.5; +5℃:108.6; R134a:-40℃:63.3; +5℃:89; R22/R407C:-40℃:91.4; +5℃:105.5; ODF(in):2-1/8; SAE(in):3/8; Overall Dimensions(mm): D:159; L:75; h:478; H: 530; M:M12; Pre-chargeqty (mL):800mL; Cubage(L):8.30L; Remark: 2

In the refrigerating capacity of the evaporation temperature (KW),R404A/R507:-40℃:51.4; +5℃:65.2; R134a:-40℃:41.3.; +5℃:56.3; R22/R407C:-40℃:56.5; +5℃:63.4; ODF(in):1-5/8; SAE(in):3/8; Overall Dimensions(mm): D:159; L:75; h:430; H: 476; M:M12; Pre-chargeqty (mL):800mL; Cubage(L):7.20L; Remark: 2

In the refrigerating capacity of the evaporation temperature (KW),R404A/R507:-40℃:41; +5℃:50.8; R134a:-40℃:33.4; +5℃:48.4; R22/R407C:-40℃:45.2; +5℃:49.8; ODF(in):1-3/8; SAE(in):3/8; Overall Dimensions(mm): D:159; L:75; h:362; H: 404; M:M12; Pre-chargeqty (mL):800mL; Cubage(L):6.20L; Remark: 2

In the refrigerating capacity of the evaporation temperature (KW),R404A/R507:-40℃:36.7; +5℃:49.0.; R134a:-40℃:28.1; +5℃:40.4; R22/R407C:-40℃:40.5 :; +5℃:47.8; ODF(in):.1-3/8; SAE(in):3/8; Overall Dimensions(mm): D:102; L:50; h:478; H: 520; M:M10; Pre-chargeqty (mL):400mL; Cubage(L):3.44L; Remark: 1

In the refrigerating capacity of the evaporation temperature (KW),R404A/R507:-40℃:30; +5℃:37.6; R134a:-40℃:22.4.; +5℃:29.9; R22/R407C:-40℃:31.8; +5℃:37.2; ODF(in):1-1/8; SAE(in):3/8; Overall Dimensions(mm): D:102; L:50; h:440; H: 482; M:M10; Pre-chargeqty (mL):400mL; Cubage(L):3.16L; Remark: 1

In the refrigerating capacity of the evaporation temperature (KW),R404A/R507:-40℃:22.8，; +5℃:29.2; R134a:-40℃:16.7; +5℃:22.4.; R22/R407C:-40℃:24.8; +5℃:28.3.; ODF(in):7/8; SAE(in):3/8; Overall Dimensions(mm): D:102; L:50; h:415; H: 455; M:M10; Pre-chargeqty (mL):400mL; Cubage(L):2.98L; Remark: 1

In the refrigerating capacity of the evaporation temperature (KW),R404A/R507:-40℃:14.2; +5℃:19.3; R134a:-40℃:11.4; +5℃:15.8; R22/R407C:-40℃:15.9; +5℃:19.5; ODF(in):5/8; SAE(in):3/8; Overall Dimensions(mm): D:102; L:50; h:335; H: 370; M:M10; Pre-chargeqty (mL):400mL; Cubage(L):2.38L; Remark: 1
